주요 스펙 요약(16)
- Common Mode Rejection Ratio Cmrr
- 86dB
- Dual Supply
- -18V~-2V;2V~18V
- features
- Single-ended to differential conversion;Differential to single-ended conversion;Overvoltage protection;Current limiting / short-circuit protection;Integrated precision resistor network
- Gain Bandwidth Product
- 550kHz
- Input Offset Voltage Drift Vos Tc
- 2uV/℃
- Maximum Power Supply Range Vdd Vss
- 36V
- Noise Density E N
- 65nV/√Hz@1kHz
- Number Of Channels
- -
- Operating Temperature
- -40℃~+85℃
- Output Current
- 10mA
- Output Type
- Differential
- package
- SOP-14
- Quiescent Current
- 200uA
- Settling Time
- 5us
- Single Supply
- 2 to 36V
- Slew Rate
- 1.1V/us
