주요 스펙 요약(21)
- Common Mode Rejection Ratio Cmrr
- 95dB
- Dual Supply
- -15 to 15V
- Gain Bandwidth Product검증
- 800kHz
- Ib Input Bias Current
- 25nA
- Input Offset Current Drift Ios Tc
- -
- Input Offset Current Ios
- 1.5nA
- Input Offset Voltage Drift Vos Tc
- 1uV/℃
- Vos Input Offset Voltage보강
- 300µV
- Maximum Power Supply Range Vdd Vss
- 30V
- Number Of Channels검증
- 4
- Operating Temperature
- -40℃~+125℃
- Output Current
- 10mA
- Quiescent Current
- 50uA
- Rail To Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Single Supply
- 3 to 30V
- Slew Rate
- 400V/ms
- Noise Density E N
- 27nV/√Hz@1kHz
- Operating Temperature Max보강
- 125°C
- Operating Temperature Min보강
- -40°C
- package
- TSSOP-14
- Voltage Gain보강
- 120dB
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)절대 최대 정격
| Supply Voltage | 36V | |
| Input Voltage | ±VSYV | |
| Differential Input Voltage | 5mA | Limit the input current to ±5 mA |
| Storage Temperature Range | -65 to +150°C |
권장 동작 조건
| Supply Voltage | 3 to 30V | |
| Operating Temperature Range | -40 to +125°C |
열 특성
- theta ja
- 112
- theta jc
- 35
오더링 코드
- R7
- Tape and Reel
