Key Specs Summary(24)
Datasheet cross-check1 matched2 enriched
- Charging Emulation
- BC1.2, Apple, China
- Integrated Flash Media Reader
- No
- Mgmt I F
- I2C
- Multi Traktech
- Yes
- Temp Range Max
- 85
- Temp Range Min
- -40
- Op Voltage
- 3.3
- Per Port Switching
- No
- phyboost
- Yes
- Port Count
- 6
- Port Map
- Yes
- Port Swap
- Yes
- Rom I F
- SPI
- Smart Hub
- Yes
- True Speed
- Yes
- Usb Speed
- USB3.2 Gen1
- Data RateEnriched
- 5Gbps
- dimensions
- 12X12X0.9mm
- msl
- MSL-3
- Number Of ChannelsEnriched
- 6
- packageVerified
- VQFN
- Pin Count
- 100
- Solder Composition
- Matte Tin
- Upstream Port
- USB3.2 Gen1
