Key Specs Summary(17)
- Breakdown Voltage Min V Br I Br V
- 16.7
- Capacitance 0 V F 1 Mhz P F Max
- 3
- Clamping Voltage Max Vc Ipp 1 A V
- 24
- Clamping Voltage Max Vc Ipp 5 A V
- 32
- Device Type
- TVS
- dimensions
- .150in
- Id Max Stand By Current A
- 1
- Idsghi Rel Dis Protection
- 3112
- line
- 2
- msl
- MSL-1
- package
- SOIC-8
- Part Type
- Arrays
- Peak Pulse Power Max 1ms Ppp W
- 500
- Pin Count
- 8
- Rated Standoff Voltage Vwm
- 15
- Test Current Ibr M A
- 1
- Solder Composition
- SnPb
