Key Specs Summary(27)
Datasheet cross-check1 enriched1 to review
- Battery Charger Detection
- Yes
- Charging Emulation
- No
- Crystal Support
- No
- gpios
- 0
- Host Based If
- No
- Integrated Usbswitch
- Yes
- iovoltage
- 1.8V
- Mgmt I F
- No
- Temp Range Max
- 85
- Temp Range Min
- -40
- Op Voltage
- 3.3
- otg
- Yes
- Port Count
- USB
- Reference Clock Freq
- 26MHz
- Rom I F
- No
- security
- No
- Data RateEnriched
- Hi-Speed
- Dead Battery Current Limiting
- No
- dimensions
- 4x4x0.9mm
- Hi Speed Switch
- No
- msl
- MSL-3
- packageReview
- VQFNDatasheet: QFN (4x4 mm) or VFBGA (3x3 mm) (p.1)
- Pin Count
- 24
- Solder Composition
- Matte Tin
- Ulpiinput Clock Mode
- No
- Upstream Port
- ULPI
- Usb Speed
- High Speed
