주요 스펙 요약(97)
- Active Die Shield
- No
- Adc Resolution Bits
- 12
- Adc Sampling Rate Ksps
- 1000
- Anti Tampering Inputs
- 8
- architecture
- 32
- Arm Neon
- Yes
- Arm Trust Zone
- Yes
- Camera Interface
- Yes
- Can Can Fd
- 2
- Cap Touch Channels
- 16
- Class B Safety Library
- No
- cpu
- Cortex-A5
- crc
- Yes
- Internal Voltage Reference Bandgap
- Yes
- Secure Bootloader
- Yes
- Type Of Can Module
- CAN
- 10 100 1000 Ethernet Mac
- 0
- 16 Bit Digital Timers
- 4
- 32 Bit Digital Timers
- 6
- 8 Bit Digital Timers
- 0
- Adc Channels
- 12
- Angular Timer
- No
- Brown Out Reset
- None
- Class D Amplifier Outputs
- Yes
- Codec Interface I2 S Ac97
- Yes
- Cpu Speed Max
- 500
- Crypto Engine
- Yes
- Debug Interface
- JTAG, SWD
- dimensions
- 14x14x1.4mm
- Direct Memory Access Dma Channels
- 51
- Ecc Bits On Nand Interface
- 32
- Ecc Program Flash Error Correction Code
- No
- Embedded Trace
- Yes
- Embedded Trace Buffer
- No
- Environmental Monitors
- No
- ethernet
- 10/100 Base-TX Mac
- Ethernet Ptp Avb Support
- No
- Ext Dram Bus
- 32
- Ext Dram Interface
- LPDDR/DDR2/LPDDR2/DDR3/LPDDR3
- External Memory Bus Interface
- Program/Data
- External Memory Encryption Descryption
- Yes
- family
- 32-bit MPU
- fpu
- Yes
- Graphic Lcd Interface
- 24
- Graphics Controller Gpu
- Yes
- H W Video Decoder
- No
- Hardware Direct Touch Channel Buttons
- 16
- Hardware Rtcc Rtc
- Yes
- Hardware Touch Matrix Nodes
- 64
- Hardware Touch Peripheral
- PTC
- I2 C
- 7
- I2 S
- 2
- I O Pins Max
- 128
- Int Dram Type
- NONE
- Integrity Check Monitor Icm
- Yes
- Internal Dram
- 0
- Internal Oscillator
- No
- Ir Da
- Yes
- L1 Cache Memory Data Kb
- 32
- L1 Cache Memory Instructions Kb
- 32
- L2 Cache
- 128
- lin
- Yes
- Media Lb
- No
- mmu
- Yes
- msl
- MSL-3
- Nand Interface
- Yes
- Number Of Cores
- 1
- Number Of Ebis
- 1
- Number Of Ethernet Ports
- 1
- Number Of Usb Modules
- 3
- Temp Range Max
- 105
- Temp Range Min
- -40
- Operation Voltage Max V
- 1.32
- Operation Voltage Min V
- 1.1
- package
- LFBGA
- Part Family
- SAMA5D2,SOC
- Part Prefix
- AT
- pincount
- 289
- Pin Count
- 289
- Pwm Outputs Including Complementary
- 10
- Pwm Resolution Bits
- 32
- qspi
- 2
- Quadrature Encoder Interface
- 2
- ram
- 128
- Sdio Sd Card E Mmc
- 2
- Secure Boot With Flash Otp
- No
- Secure Key Storage Bits
- 544
- Solder Composition
- Lf35
- spi
- 7
- Supported In Mplab Code Configurator
- No
- Temp Sensor
- Yes
- timers
- 10
- Touch Library Support
- Yes
- U S Art
- 10
- usb
- High Speed
- Vbat Vddbu Battery Backup
- Yes
- Watch Dog Timer
- Yes
