- Active Die Shield
- No
- Adc Modules Min
- 1
- Adc Resolution Bits
- 10
- Adc Sampling Rate Ksps
- 312
- Adc With Computation
- No
- Anti Tampering Inputs
- 0
- architecture
- 32
- Arm Neon
- No
- Arm Trust Zone
- No
- Automotive Qualified
- 0
- Can Can Fd
- 0
- Capture Compare Pwm Ccp
- 0
- Configurable Logic Cell Clc Ccl
- 0
- Internal Voltage Reference Bandgap
- Yes
- Secure Bootloader
- No
- Type Of Can Module
- None
- 10 100 1000 Ethernet Mac
- 0
- 16 Bit Digital Timers
- 6
- 32 Bit Digital Timers
- 0
- 8 Bit Digital Timers
- 0
- Adc Channels
- 4
- Adc Sample Hold
- 1
- Angular Timer
- No
- Auxiliary Flash Kb
- 0
- Bootload Capable
- No
- Brown Out Reset
- None
- Camera Interface
- Yes
- Cap Touch Channels
- 0
- Class B Safety Library
- No
- Class D Amplifier Outputs
- No
- Code Guard Security
- None
- Codec Interface I2 S Ac97
- Yes
- Comparator Max Speed Ns
- 0
- Complementary Waveform Generator Cwg Complementary Output Generator Cog Max
- 0
- cpu
- ARM926
- Cpu Speed Max
- 180
- Cpu Speed Mips Dmips
- 198
- crc
- Yes
- Crypto Engine
- No
- Dac Outputs
- 0
- Dac Resolution Bits
- 0
- Data Eeprom Bytes
- 0
- Data Signal Modulator Dsm
- 0
- Debug Interface
- JTAG, DCC
- Diff Adc Inputs
- 0
- dimensions
- 28x28x3.37mm
- Direct Memory Access Dma Channels
- 25
- Ecc Bits On Nand Interface
- 1
- Ecc Program Flash Error Correction Code
- No
- Embedded Trace
- No
- Embedded Trace Buffer
- No
- Enhanced Capture Compare Pwm Eccp
- 0
- Environmental Monitors
- No
- ethernet
- 10/100 Base-TX Mac
- Ext Dram Bus
- 32
- Ext Dram Interface
- SDRAM/LPSDRAM
- External Memory Bus Interface
- Program/Data
- External Memory Encryption Descryption
- No
- family
- 32-bit MPU
- focus
- No
- fpu
- No
- Graphic Lcd Interface
- No
- Graphics Controller Gpu
- No
- H W Video Decoder
- No
- Hardware Cap Voltage Divider
- No
- Hardware Direct Touch Channel Buttons
- 0
- Hardware Limit Timer
- No
- Hardware Qtouch Acquisition
- No
- Hardware Rtcc Rtc
- Yes
- Hardware Touch Matrix Nodes
- 0
- Hardware Touch Peripheral
- None
- I2 C
- 1
- I2 S
- 0
- I O Pins Max
- 96
- Input Capture
- 6
- Integrity Check Monitor Icm
- No
- Internal Dram
- 0
- Internal Oscillator
- 32KHz
- Ir Da
- Yes
- Jtag Max
- Debug/Program/Boundary Scan
- L1 Cache Memory Data Kb
- 8
- L1 Cache Memory Instructions Kb
- 8
- L2 Cache
- 0
- lin
- No
- Low Power
- No
- Low Voltage Detection
- None
- Media Lb
- No
- mmu
- Yes
- Motor Control Pwm Outputs
- 0
- msl
- MSL-3
- Mssp Spi I2 C
- 0
- Multiple Flash Panels
- No
- Multiple Output Ccp Mccp
- 0
- Nand Interface
- Yes
- Number Of Comparators
- 0
- Number Of Dacs
- 0
- Number Of Ebis
- 1
- Number Of Ethernet Ports
- 1
- Number Of Op Amps
- 0
- Number Of Pwm Time Bases
- 6
- Number Of Usb Modules
- 3
- Numerically Controlled Oscillator Nco
- 0
- Temp Range Max
- 85
- Temp Range Min
- -40
- Operation Voltage Max V
- 1.95
- Operation Voltage Min V
- 1.65
- Output Compare Channels
- 6
- package
- PQFP
- Parallel Port
- EBI
- Part Family
- SAM9200
- Part Prefix
- AT91
- Peripheral Pin Select Pin Muxing
- Yes
- Peripheral Trigger Generator
- No
- Pin Count
- 208
- pincount
- 208
- Power On Reset
- Yes
- Program Memory Size Kb
- 0
- Programmable Gain Amp Pga
- 0
- Pwm Outputs Including Complementary
- 6
- Pwm Resolution Bits
- 16
- Pwm Resolution Ns
- 8
- qspi
- 0
- Quadrature Encoder Interface
- 0
- ram
- 8
- Ram Bytes
- 8192
- Sdio Sd Card E Mmc
- 2
- Secure Boot With Flash Otp
- No
- Secure Key Storage Bits
- 0
- Segmented Lcd Of Segments
- 0
- Signal Measurement Timer
- 0
- Single Output Ccp Sccp
- 0
- Slope Compensation Programmable Ramp Generator
- No
- smps
- 0
- Solder Composition
- MatteTin
- spi
- 2
- sqi
- 0
- Ssp Spi I2 C
- 0
- Stand Alone Pwm
- 6
- Standalone Output Compare Standard Pwm
- 6
- Temp Sensor
- No
- timers
- 6
- Touch Library Support
- No
- U S Art
- 7
- usb
- Full Speed
- Vbat Vddbu Battery Backup
- Yes
- Watch Dog Timer
- Yes
- xlp
- No
- Zero Cross Detect
- No
