국내 재고 없음
이 부품에 대한 견적을 요청하시면 판매자들이 가격을 제시합니다.
주요 스펙 요약(30)
- collector_emitter_breakdown_voltage
- 80V
- collector_emitter_saturation_voltage
- 400mV
- collector_emitter_voltage_max
- 400mV
- current_transfer_ratio
- 320%
- fall_time
- 29us
- forward_current
- 5mA
- height
- 2mm
- input_current
- 60mA
- input_type
- DC
- isolation_voltage
- 3.75kV
- isolation_voltage_max
- 3.75kV
- lead_free
- Lead Free
- length
- 4.4mm
- max_collector_current
- 100mA
- max_input_current
- 60mA
- package_case
- SOP
- lifecycle_status
- Active
- max_output_voltage
- 80V
- max_power_dissipation
- 170mW
- mount_type
- Surface Mount
- number_of_channels
- 1
- operating_temperature_max
- 110°C
- operating_temperature_min
- -55°C
- output_current_per_channel
- 50mA
- output_voltage
- 80V
- package_quantity
- 1
- packing_style
- Tape and Reel
- reverse_voltage_dc
- 6V
- rohs_compliant
- Yes
- width
- 3.85mm
