국내 재고 없음
이 부품에 대한 견적을 요청하시면 판매자들이 가격을 제시합니다.
주요 스펙 요약(39)
- clamping_voltage
- 29.2V
- clamping_voltage_max
- 29.2V
- diode_type
- ZENER
- direction
- Unidirectional
- height
- 0.09inch
- lead_free
- Lead Free
- leakage_current
- 1uA
- length
- 0.177inch
- max_breakdown_voltage
- 22.1V
- max_forward_surge_current_ifsm
- 40A
- max_power_dissipation
- 400W
- max_reverse_leakage_current
- 1uA
- min_breakdown_voltage
- 20V
- operating_temperature_max
- 150°C
- operating_temperature_min
- -55°C
- package_case
- R-PDSO-C2
- contact_voltage_rating_dc
- 18V
- lifecycle_status
- Active
- max_surge_current
- 13.7A
- number_of_channels
- 1
- number_of_elements
- 1
- number_of_unidirectional_channels
- 1
- operating_supply_voltage
- 18V
- package
- R-PDSO-C2
- package_quantity
- 1800
- packing_style
- Tape and Reel
- peak_pulse_current
- 13.7A
- peak_pulse_power
- 400W
- polarity
- Unidirectional
- power_dissipation
- 400W
- power_line_protection
- No
- radiation_hardening
- No
- reach_compliant
- Unknown
- reverse_breakdown_voltage
- 20V
- reverse_standoff_voltage
- 18V
- series
- TransZorb®
- terminal_type
- SMD/SMT
- width
- 0.11inch
- working_voltage
- 3.5V
