주요 스펙 요약(35)
- case_code_imperial
- 2525
- case_code_metric
- 6363
- contact_current_rating
- 4.5A
- core_material
- Metal, Composite, Ferrite
- dc_resistance_dcr
- 60mΩ
- depth
- 6.72mm
- height
- 3mm
- inductance
- 6.8uH
- inductance_tolerance
- 20%
- lead_free
- Lead Free
- length
- 6.86mm
- max_dc_current
- 8A
- military_standard
- Not
- operating_temperature_max
- 125°C
- operating_temperature_min
- -55°C
- package_case
- 2525
- lifecycle_status
- Active
- mount_type
- Surface Mount
- package
- 2525
- package_quantity
- 2000
- packing_style
- Tape and Reel
- radiation_hardening
- No
- rated_current_max
- 4.5A
- reach_compliant
- Unknown
- rms_current_irms
- 4.5A
- rohs_compliant
- Yes
- saturation_current
- 8A
- self_resonant_frequency
- 5MHz
- series
- IHLP-2525CZ-01
- series_resistance
- 60mΩ
- shielding
- Shielded
- terminal_type
- SMD/SMT
- test_frequency
- 100kHz
- tolerance
- 20%
- width
- 6.47mm
