국내 재고 없음
이 부품에 대한 견적을 요청하시면 판매자들이 가격을 제시합니다.
주요 스펙 요약(34)
- case_code_imperial
- 1812
- case_code_metric
- 4532
- contact_current_rating
- 110mA
- core_material
- Ferrite
- dc_current
- 110mA
- dc_resistance_dcr
- 8Ω
- depth
- 3.4mm
- height
- 3.2mm
- height_seated_max
- 0.134inch
- inductance
- 100uH
- inductance_tolerance
- 5%
- lead_free
- Lead Free
- length
- 4.5mm
- max_dc_current
- 110mA
- operating_temperature_max
- 105°C
- package_case
- CHIP
- lifecycle_status
- LTB
- military_standard
- Not
- mount_type
- Surface Mount
- operating_temperature_min
- -40°C
- package
- CHIP
- package_quantity
- 500
- packing_style
- Tape and Reel
- q_factor
- 40
- rated_current_max
- 110mA
- reach_compliant
- No
- rohs_compliant
- Yes
- self_resonant_frequency
- 8MHz
- series
- NL
- shielding
- Unshielded
- terminal_type
- SMD/SMT
- test_frequency
- 796kHz
- tolerance
- 5%
- width
- 0.126inch
