주요 스펙 요약(35)
- certifications
- UL, CSA
- coil_current
- 2.9mA
- coil_power
- 70mW
- coil_resistance
- 8.229kΩ
- coil_type
- Non-Latching
- coil_voltage_dc
- 24V
- contact_current_rating
- 1A
- contact_material
- Gold, Silver
- depth
- 7.4mm
- life_hours
- 2Hour
- height
- 8.2mm
- insertion_loss
- 0.8dB
- lead_free
- Lead Free
- length
- 15mm
- operating_temperature_max
- 70°C
- package_case
- ROHS COMPLIANT
- contact_configuration
- DPDT
- max_voltage_rating_dc
- 110V
- contact_voltage_rating_dc
- 110V
- lifecycle_status
- Active
- mount_type
- Through Hole, PCB
- operate_time
- 5ms
- operating_temperature_min
- -40°C
- package
- ROHS COMPLIANT
- package_quantity
- 40
- packing_style
- Rail/Tube
- radiation_hardening
- No
- reach_compliant
- Unknown
- relay_type
- General Purpose
- release_time
- 5ms
- rohs_compliant
- Yes
- series
- TX-S
- terminal_type
- PC Pin
- weight
- 2g
- width
- 7.4mm
