국내 재고 없음
이 부품에 대한 견적을 요청하시면 판매자들이 가격을 제시합니다.
주요 스펙 요약(32)
- actuator_type
- PLUNGER
- certifications
- UL, CSA, CE, IEC, NEMA
- contact_type
- 1
- contact_configuration
- 1
- contact_current_rating
- 10A
- max_voltage_rating_ac
- 480V
- max_voltage_rating_dc
- 250V
- depth
- 21.7mm
- differential_travel
- 0.008inch
- life_expectancy
- 500000Cycles
- length
- 69.4mm
- mechanical_life
- 10000000Cycles
- mount_type
- Panel, Screw
- operating_force
- 1200gf
- operating_temperature_max
- 80°C
- operating_temperature_min
- -10°C
- voltage_rating_ac
- 250V
- contact_voltage_rating_dc
- 30V
- lifecycle_status
- Volume Production
- operating_position
- 1.866inch
- orientation
- Straight
- overtravel
- 0.118inch
- package_quantity
- 1
- packing_style
- Bulk
- pretravel
- 0.06inch
- ratings
- IP67, Waterproof, Dust Tight
- reach_compliant
- Unknown
- rohs_compliant
- Yes
- series
- ZC
- switch_function
- On-Mom
- terminal_type
- Screw
- width
- 70mm
