국내 재고 없음
이 부품에 대한 견적을 요청하시면 판매자들이 가격을 제시합니다.
주요 스펙 요약(33)
- collector_emitter_voltage_vceo
- 28V
- fall_time
- 20us
- forward_current
- 20mA
- height
- 10mm
- input_current
- 50mA
- lead_free
- Lead Free
- length
- 5mm
- low_level_output_current
- 16mA
- max_collector_current
- 16mA
- max_output_current
- 16mA
- max_power_dissipation
- 250mW
- max_reverse_current
- 10nA
- mount_type
- Through Hole, PCB
- number_of_channels
- 1
- operating_temperature_max
- 75°C
- operating_temperature_min
- -40°C
- lifecycle_status
- Active
- number_of_elements
- 1
- operating_supply_current
- 3.2mA
- operating_supply_voltage
- 16V
- output
- TRANSISTOR
- output_configuration
- NPN - Open Collector
- package_quantity
- 500
- packing_style
- Bulk
- power_dissipation
- 250mW
- propagation_delay
- 20us
- reach_compliant
- Unknown
- reverse_breakdown_voltage
- 4V
- reverse_voltage_dc
- 4V
- rohs_compliant
- Yes
- terminal_type
- Solder
- wavelength
- 940nm
- width
- 12.2mm
