주요 스펙 요약(38)
- amplifier_type
- GENERAL PURPOSE
- bandwidth
- 10MHz
- common_mode_rejection_ratio
- 70dB
- gain_bandwidth_product
- 10MHz
- height
- 1.25mm
- input_bias_current
- 1pA
- input_offset_voltage_max
- 5mV
- input_offset_voltage_vos
- 3mV
- lead_free
- Lead Free
- length
- 8.65mm
- max_supply_voltage
- 5.5V
- min_supply_voltage
- 2.4V
- mount_type
- Surface Mount
- operating_temperature_max
- 125°C
- operating_temperature_min
- -40°C
- package_case
- SOP, SOP14,.25
- lifecycle_status
- Active
- number_of_amplifiers
- 4
- number_of_channels
- 4
- number_of_circuits
- 4
- number_of_elements
- 4
- operating_supply_current
- 1mA
- output_current
- 25mA
- output_current_per_channel
- 25mA
- package
- SOP, SOP14,.25
- package_quantity
- 57
- packing_style
- Rail/Tube
- power_supply_rejection_ratio_psrr
- 70dB
- radiation_hardening
- No
- reach_compliant
- No
- rohs_compliant
- Yes
- slew_rate
- 7V/µs
- slew_rate_nom
- 7V/µs
- supply_current
- 1mA
- technology
- CMOS
- unity_gain_bandwidth_product
- 10MHz
- voltage_gain
- 110dB
- width
- 3.9mm
