국내 재고 없음
이 부품에 대한 견적을 요청하시면 판매자들이 가격을 제시합니다.
주요 스펙 요약(36)
- contact_current_rating
- 6A
- core_material
- Ferrite, Composite
- dc_current
- 6A
- dc_resistance_dcr
- 30mΩ
- depth
- 7mm
- height
- 3mm
- height_seated_max
- 0.118inch
- inductance
- 3.3uH
- inductance_tolerance
- 20%
- lead_free
- Lead Free
- length
- 7.4mm
- max_dc_current
- 13.5A
- military_standard
- Not
- operating_temperature_max
- 125°C
- operating_temperature_min
- -55°C
- package_case
- 2827
- lifecycle_status
- Active
- mount_type
- Surface Mount
- package
- 2827
- package_quantity
- 1500
- packing_style
- Tape and Reel
- radiation_hardening
- No
- rated_current_max
- 6A
- reach_compliant
- No
- rms_current_irms
- 6A
- rohs_compliant
- Yes
- saturation_current
- 13.5A
- self_resonant_frequency
- 5MHz
- series
- HCM0703
- series_resistance
- 30mΩ
- shielding
- Shielded
- terminal_type
- SMD/SMT
- test_frequency
- 100kHz
- tolerance
- 20%
- weight
- 0.016oz
- width
- 0.26inch
