국내 재고 없음
이 부품에 대한 견적을 요청하시면 판매자들이 가격을 제시합니다.
주요 스펙 요약(12)
- con
- 23pF
- Data Rate보강
- 300MHz
- Max Supply Voltage보강
- 6V
- Number Of Channels
- 4
- ron
- 5Ω
- Operating Temperature
- -40℃~+85℃
- Operating Temperature Max보강
- 85°C
- Operating Temperature Min보강
- -40°C
- package
- QSOP-16-150mil
- Pin Count보강
- 16
- Supply Current보강
- 1
- Voltage Supply
- 3.3V;5V
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)핀 배치 · QSOP · 16 핀
| # | Name | Type | Function |
|---|---|---|---|
| 1 | IN | input | Logic Control Input |
| 2 | S1A | bidirectional | A-Side Source Terminal of Mux1 |
| 3 | S1B | bidirectional | B-Side Source Terminal of Mux1 |
| 4 | D1 | bidirectional | Drain Terminal of Mux1 |
| 5 | S2A | bidirectional | A-Side Source Terminal of Mux2 |
| 6 | S2B | bidirectional | B-Side Source Terminal of Mux2 |
| 7 | D2 | bidirectional | Drain Terminal of Mux2 |
| 8 | GND | power in | Ground Reference |
| 9 | D3 | bidirectional | Drain Terminal of Mux3 |
| 10 | S3B | bidirectional | B-Side Source Terminal of Mux3 |
| 11 | S3A | bidirectional | A-Side Source Terminal of Mux3 |
| 12 | D4 | bidirectional | Drain Terminal of Mux4 |
| 13 | S4B | bidirectional | B-Side Source Terminal of Mux4 |
| 14 | S4A | bidirectional | A-Side Source Terminal of Mux4 |
| 15 | EN | input | Mux Enable Logic Input |
| 16 | VDD | power in | Positive Power Supply Voltage |
절대 최대 정격
| VDD to GND | -0.3 to +6V | |
| Analog, Digital Inputs | -0.3 to VDD + 0.3 or 30V or mA | whichever occurs first |
| Continuous Current, S or D | 100mA | |
| Peak Current, S or D | 300mA | pulsed at 1 ms, 10% duty cycle maximum |
| Operating Temperature Range | -40 to +85°C | Industrial (B Version) |
| Storage Temperature Range | -65 to +150°C | |
| Junction Temperature | 150°C | |
| QSOP Package, Power Dissipation | 566mW |
권장 동작 조건
| Operating Temperature Range | -40 to +85°C | Industrial (B Version) |
열 특성
- theta ja
- 149.97
등급 · 신뢰성
- esd hbm
- 2
오더링 코드
- Z
- RoHS Compliant Part
