국내 재고 없음
이 부품에 대한 견적을 요청하시면 판매자들이 가격을 제시합니다.
주요 스펙 요약(9)
- con
- 145pF
- Number Of Channels
- 1
- ron
- 2.5Ω
- Operating Temperature
- -40℃~+85℃
- Operating Temperature Max보강
- 85°C
- Operating Temperature Min보강
- -40°C
- package
- SOT-23-6
- Pin Count보강
- 6
- Voltage Supply
- 2.7V~5.5V;-5.5V~5.5V
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)핀 배치 · 6-Lead SOT-23 · 6 핀
| # | Name | Type | Function |
|---|---|---|---|
| 1 | VDD | power in | Most Positive Power Supply Potential |
| 2 | S | bidirectional | Source Terminal. Can be an input or output |
| 3 | VSS | power in | Most Negative Power Supply Potential |
| 4 | GND | power in | Ground (0 V) Reference |
| 5 | D | bidirectional | Drain Terminal. Can be an input or output |
| 6 | IN | input | Logic Control Input |
절대 최대 정격
| VDD to VSS | 13V | |
| VDD to GND | -0.3 to +6.5V | |
| VSS to GND | +0.3 to -6.5V | |
| Analog Inputs | VSS - 0.3 to VDD + 0.3V | |
| Digital Inputs | -0.3 to VDD + 0.3 or 30 mAV/mA | whichever occurs first |
| Continuous Current, S or D | 100mA | |
| Peak Current, S or D | 200mA | Pulsed at 1 ms, 10% Duty Cycle Max |
| Storage Temperature Range | -65 to +150°C | |
| Junction Temperature | 150°C |
권장 동작 조건
| Operating Temperature Range | -40 to +85°C | Industrial (B Version) |
열 특성
- unit
- °C/W
- theta ja
- 229.6
- theta jc
- 91.99
오더링 코드
- REEL7
- 6-Lead SOT-23, RJ-6 package
