주요 스펙 요약(20)
- Common Mode Rejection Ratio Cmrr
- 146dB
- features
- External resistor gain;Overvoltage protection
- Gain Bandwidth Product
- 2.2MHz
- Ib Input Bias Current
- 500pA
- Input Offset Current Ios
- 150pA
- Input Offset Voltage Drift Vos Tc
- 300nV/℃
- Vos Input Offset Voltage
- 70uV
- Maximum Power Supply Range Vdd Vss
- 36V
- Noise Density E N
- 8nV/√Hz@1kHz
- Number Of Channels
- 1
- Operating Temperature
- -40℃~+125℃
- Output Current
- 20mA
- Output Type
- -
- Quiescent Current
- 368uA
- Settling Time
- 13us
- Slew Rate
- 0.8V/us
- Dual Supply
- -18V~-2.3V;2.3V~18V
- package
- LFCSP-8(3x3)
- Rail To Rail
- Rail-to-rail output
- Single Supply
- 4.6 to 36V
