주요 스펙 요약(18)
- Common Mode Rejection Ratio Cmrr
- 100dB;86dB
- Differential Voltage
- ±5.5V
- Dual Supply
- -
- gain
- 20V/V
- Gain Bandwidth Product
- 250kHz
- Ib Input Bias Current
- -
- Input Offset Current Ios
- -
- Input Offset Voltage Drift Vos Tc
- 0.4uV/℃
- Vos Input Offset Voltage
- -
- Number Of Channels
- 1
- Operating Temperature
- -40℃~+125℃
- Output Current
- -
- Quiescent Current
- -
- Single Supply
- -
- Slew Rate
- 1V/us
- Vcm Common Mode Voltage
- -2 to 70V
- Noise Density E N
- -
- package
- MSOP-8
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)절대 최대 정격
| Supply Voltage | 6V | |
| Input Voltage Range | -2 to +70V | Continuous |
| Input Voltage Range | -4 to +85V | Tolerance range |
| Differential Input Voltage Range | 5.5V | |
| Reverse Supply Voltage | 0.3V | |
| ESD HBM | 2000V |
권장 동작 조건
| Supply Voltage | 2.7 to 5.5V | |
| Operating Temperature | -40 to +125°C |
등급 · 신뢰성
- aec q
- W suffix indicates automotive grade
- esd hbm
- 2000 V
오더링 코드
- Z
- RoHS compliant
- W
- Automotive qualified
- -RL
- 13 inch tape and reel
