주요 스펙 요약(12)
데이터시트 대조일치 2보강 5
- Coil Resistance보강
- 0.26Ω
- Contact Current Rating보강
- 3A
- Contact Voltage Ac보강
- 690V
- Lifecycle Status
- Active
- Max Supply Current
- 45A
- Max Supply Voltage
- 690V
- Operating Temperature Max검증
- 70°C
- Operating Temperature Min검증
- -25°C
- package보강
- Screw terminal
- Reach Compliant
- No
- Terminal Type보강
- Screw terminal
- width
- 45mm
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)핀 배치 · Screw terminal · 9 핀
| # | Name | Type | Function |
|---|---|---|---|
| 1L1 | Main circuit input | power in | Motor current flow |
| 3L2 | Main circuit input | power in | Motor current flow |
| 5L3 | Main circuit input | power in | Motor current flow |
| 2T1 | Auxiliary contact | output | Signaling/Trip indication |
| 4T2 | Auxiliary contact | output | Signaling/Trip indication |
| 6T3 | Auxiliary contact | output | Signaling/Trip indication |
| 95 | Tripping contact | output | Control load contactor |
| 96 | Tripping contact | output | Control load contactor |
| 97 | Signaling contact | output | Status indication |
패키지 정보
- package
- Screw terminal
절대 최대 정격
| Rated operational voltage Ue | 690V | a.c. |
권장 동작 조건
| Ambient air temperature (Operation) | -25 ... +70°C | open - compensated |
| Duty time | 100% |
오더링 코드
- EF45-45
- Setting range 15.0 … 45.0 A
