주요 스펙 요약(12)
데이터시트 대조일치 2보강 4검토 1
- Coil Resistance보강
- 447Ω
- Contact Voltage Ac보강
- 690V
- Lifecycle Status
- Active
- Max Supply Current
- 320mA
- Max Supply Voltage
- 690V
- Mount Type검토
- External데이터시트: Mount on the connector and tighten the screws of the main circuit terminals (p.5)
- Operating Temperature Max검증
- 70°C
- Operating Temperature Min검증
- -25°C
- package보강
- EF19
- Reach Compliant
- No
- Terminal Type보강
- Screw terminal
- width
- 45mm
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)핀 배치 · Screw terminal · 8 핀
| # | Name | Type | Function |
|---|---|---|---|
| 1L1 | Main circuit input | input | Motor current flow |
| 3L2 | Main circuit input | input | Motor current flow |
| 5L3 | Main circuit input | input | Motor current flow |
| 2T1 | Auxiliary output | output | Signaling contact 97-98 |
| 4T2 | Auxiliary output | output | Signaling contact 97-98 |
| 6T3 | Auxiliary output | output | Signaling contact 97-98 |
| 95 | Tripping contact | output | Control load contactor |
| 96 | Tripping contact | output | Control load contactor |
패키지 정보
- package
- EF19
권장 동작 조건
| Ambient air temperature (Operation) | -25 … +70°C | open - compensated |
오더링 코드
- EF19-0.32
- Setting range 0.10 … 0.32 A
