주요 스펙 요약(19)
- Common Mode Rejection Ratio
- 90dB
- Dual Supply
- -
- features
- Built-in compensation
- Gain Bandwidth Product
- 10MHz
- Ib Input Bias Current
- 10pA
- Input Offset Current Drift Ios Tc
- -
- Input Offset Current Ios
- 10pA
- Input Offset Voltage Drift Vos Tc
- 100nV/℃
- Input Offset Voltage Vos
- 400uV
- Input Voltage Noise Density
- -
- Maximum Power Supply Range Vdd Vss
- -
- Number Of Channels
- 1
- Operating Temperature
- -40℃~+125℃
- Output Current
- -
- Quiescent Current
- 1.2mA
- Slew Rate
- 8V/us
- package
- DFN-8(2x2)
- Rail To Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Single Supply
- -
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)핀 배치 · DFN0.8x0.8-4 · 5 핀
| # | Name | Type | Function |
|---|---|---|---|
| 1 | Out | output | Output |
| 2 | -In | input | Inverting input |
| 3 | +In | input | Non-inverting input |
| 4 | +Vs | power in | Positive power supply |
| 5 | -Vs | power in | Negative power supply |
