주요 스펙 요약(16)
- Common Mode Rejection Ratio
- 120dB
- features
- -
- Gain Bandwidth Product
- 2.5MHz
- Ib Input Bias Current
- 10pA
- Input Offset Current Ios
- 10pA
- Input Offset Voltage Drift Vos Tc
- 2uV/℃
- Input Offset Voltage Vos
- 100uV
- Input Voltage Noise Density
- 25nV/√Hz@1kHz
- Number Of Channels
- 2
- Operating Temperature
- -40℃~+125℃
- Output Current
- 40mA
- package
- SOP-8
- Quiescent Current
- 800uA
- Rail To Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Single Supply
- 2.7 to 16V
- Slew Rate
- 2V/us
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)핀 배치 · SOP8 · 5 핀
| # | Name | Type | Function |
|---|---|---|---|
| 1 | +Vs | power in | Positive power supply |
| 2 | -In | input | Inverting input |
| 3 | +In | input | Noninverting input |
| 4 | -Vs | power in | Negative power supply |
| 5 | Out | output | Output |
절대 최대 정격
| Supply Voltage (+VS) – (−VS) | 18V | |
| Maximum Junction Temperature (TJ) | 150°C |
권장 동작 조건
| Supply Voltage Single Supply | 2.7V | min |
| Supply Voltage Single Supply | 16V | max |
| Operating Temperature Range (TA) | -40°C | min |
| Operating Temperature Range (TA) | 125°C | max |
등급 · 신뢰성
- unit
- kV
- esd cdm
- 1.5
- esd hbm
- 3
오더링 코드
- -SO1R
- SOP8
