주요 스펙 요약(18)
- Common Mode Rejection Ratio
- -
- Dual Supply
- -
- Gain Bandwidth Product
- -
- Ib Input Bias Current
- -
- Input Offset Current Drift Ios Tc
- -
- Input Offset Current Ios
- 1pA
- Input Offset Voltage Drift Vos Tc
- -
- Input Offset Voltage Vos
- -
- Input Voltage Noise Density
- -
- Maximum Power Supply Range Vdd Vss
- -
- Number Of Channels
- 1
- Operating Temperature
- -40℃~+125℃
- Output Current
- 100mA
- Quiescent Current
- -
- Rail To Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Slew Rate
- -
- package
- SOT-353
- Single Supply
- -
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)핀 배치 · SOT23-5 · 5 핀
| # | Name | Type | Function |
|---|---|---|---|
| 1 | Out | output | Output |
| 2 | -Vs | power in | Negative power supply |
| 3 | +In | input | Non-inverting input |
| 4 | -In | input | Inverting input |
| 5 | +Vs | power in | Positive power supply |
절대 최대 정격
| Supply Voltage | 7V | |
| Input Voltage | -0.3 to +0.3V | |
| Input Current | 10mA | |
| Maximum Junction Temperature | 150°C |
권장 동작 조건
| Supply Voltage | 2.1 to 6.0V | |
| Operating Temperature Range | -40 to 125°C |
열 특성
- cond
- SOT23-5
- unit
- °C/W
- theta ja
- 250
- theta jc
- 81
등급 · 신뢰성
- unit
- kV
- esd cdm
- 2
- esd hbm
- 8
오더링 코드
- -CR
- SOT23-5
