주요 스펙 요약(15)
- Common Mode Rejection Ratio
- 106dB
- Gain Bandwidth Product
- 10MHz
- Ib Input Bias Current
- 0.3pA
- Input Offset Current Ios
- 0.3pA
- Input Offset Voltage Drift Vos Tc
- 1uV/℃
- Input Offset Voltage Vos
- 250uV
- Input Voltage Noise Density
- 8.2nV/√Hz@1kHz
- Number Of Channels
- 2
- Operating Temperature
- -40℃~+125℃
- Output Current
- 70mA
- package
- SOT-23-8
- Quiescent Current
- 1.4mA
- Rail To Rail
- Rail-to-Rail Input, Rail-to-Rail Output
- Single Supply
- 2.2 to 5.5V
- Slew Rate
- 7V/us
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)절대 최대 정격
| Supply Voltage: V+ − V− | 7V | |
| Input Voltage | -0.3 to +0.3V | |
| Input Current: +IN, –IN | -20 to +20mA | |
| Current at Supply Pins | -60 to +60mA | |
| Maximum Junction Temperature | 150°C |
권장 동작 조건
| Operating Temperature Range | -40 to 125°C | |
| Storage Temperature Range | -65 to 150°C |
열 특성
- theta ja
- 196
- theta jc
- 70
등급 · 신뢰성
- esd cdm
- 1
- esd hbm
- 4
오더링 코드
- -TR
- SOT23-8 Tape and Reel
