주요 스펙 요약(19)
- Common Mode Rejection Ratio
- 120dB
- Dual Supply
- -
- features
- -
- Gain Bandwidth Product
- 900kHz
- Ib Input Bias Current
- 60pA
- Input Offset Current Drift Ios Tc
- -
- Input Offset Current Ios
- 60pA
- Input Offset Voltage Drift Vos Tc
- 7uV/℃
- Input Offset Voltage Vos
- 100uV
- Input Voltage Noise Density
- 70nV/√Hz@1kHz
- Maximum Power Supply Range Vdd Vss
- -
- Number Of Channels
- -
- Operating Temperature
- -40℃~+125℃
- Output Current
- 30mA
- Quiescent Current
- 150uA
- Slew Rate
- 500V/ms
- package
- SOT-23-5
- Rail To Rail
- Rail-to-rail output
- Single Supply
- 3 to 36V
데이터시트 추출 정보
데이터시트에서 직접 추출한 사실 (출처 명시)절대 최대 정격
| Supply Voltage, (+VS)– (-VS) | 40V | |
| Input Voltage | -VS - 0.3 to +VS + 0.3 | |
| Differential Input Voltage | +VS - (-VS) | |
| Input Current: +IN, –IN | 10mA | |
| Maximum Operating Junction Temperature | 150°C |
권장 동작 조건
| Operating Temperature Range | -40 to 125°C | |
| Supply Voltage Range | 3 to 36V |
열 특성
- unit
- °C/W
- theta ja
- 250
- theta jc
- 81
등급 · 신뢰성
- unit
- kV
- esd cdm
- 2
- esd hbm
- 3
오더링 코드
- S5TR
- SOT23-5 Package, Tape and Reel
